A simple to use, low cost vibration meter that records, analyses and displays vibration signals on a colour screen at the push of a button. Overall vibration values are displayed with colour coded alarm levels for ISO values and bearing condition. The fully dynamic cursor displays frequency and amplitude values. Colour coded frequency band alarms based on run speed can be displayed to diagnose machine faults such as balance, alignment and looseness. Readings are easily saved and recalled with all alarm levels and settings stored in non-volatile flash memory. Run speed and machine type are entered with the simple to use set-up wizard.Size: 200 mm x 60mm x 26mm.Weight: 280g (not including magnet).Environmental: water, sand and dust: IP67 waterproof, operating: 0C to 50C, storage: -20C to 70C.Power supply: 2x AA batteries.Displayed frequency units: Hertz (Hz), RPM or CPM.Input range: +/- 50g.Dynamic range: 72 dB (0.05g resolution).VA diagnostic bands (RPM = run speed):Unbalance 1x RPM.Misalignment 2x RPM.Looseness 3x RPM.Accessories: screw in probe tip (1/4" UNF 28). Nylon carrying case.Options: accelerometer mounting magnet. Extended probe tip (stinger).
